SEQURE SQESC 28120 Brushless Electric Speed Controller 2-8S Power Supply AM32 Firmware
Rs 5,500.00
Exclusive of GST
(0 reviews)
The SEQURE SQESC 28120 Brushless Electronic Speed Controller (ESC) is a high-performance 120A ESC designed for demanding RC applications, including FPV drones, UAVs, RC cars, fixed-wing aircraft, and combat robotics. Supporting 2–8S LiPo input and powered by the advanced AM32 firmware, it delivers ultra-smooth throttle response, fast motor startup, and precise control. Built with a 32-bit STM32 processor, premium MOSFETs, and an efficient aluminum heatsink, it ensures reliable operation under high-current loads. With support for DShot, PWM, OneShot, and MultiShot protocols, plus reverse, brake, and comprehensive protection features, the SQESC 28120 is the perfect ESC for high-performance robotics and competitive combat robot builds.
1
Technical Specifications
ModelSQESC 28120
Input voltageDC 7V-35V（2-8S Lipo)
Continuous current (good heat dissipation)120A
Maximum current (good heat dissipation)150A
Support firmwareAM32
Programming parameter adjustmentSupport
Throttle calibrationSupport
Timing angle settingSupport
Current detectionSupport
Motor steering settingsSupport
Power cable(Recommended)14AWG
Product Size50*20*17mm
Key Features
Discover what makes SEQURE SQESC 28120 Brushless Electric Speed Controller 2-8S Power Supply AM32 Firmware stand out from the rest.
- Adopting 32-bit high-performance processor STM32G071, with a working frequency of up to 64MHz and maximum support 128KHz motor PWM frequency.
- Adopts high-power MOSFET, and combines with CNC metal radiator, this esc dissipates heat effectively under high current load and works stably & continuously.
- Supports multiple motion modes such as unidirectional, bidirectional, and braked motors.
- Supports multiple protections such as low voltage protection, temperature protection, locked rotor protection, and current protection.
- The ESC automatically detects the throttle signal when it is powered on, supports all Dshot signals, and also supports signal protocols such as PWM, Oneshot and Multishot.
- Visual programming parameter adjustment tool supports motor timing, throttle calibration, current detection, motor steering, telemetry signal and other settings.
